STM32 Power Line Communication based on STMicroelectronics ST7580 Expansion Board
The X-NUCLEO-PLM01A1 expansion board for STM32 Nucleo is based on the ST7580 FSK, PSK multi-mode power line networking system-on-chip. It provides an affordable and easy-to-use solution for the development of connectivity applications based on power line communication. It lets you easily evaluate the communication features of the ST7580 based on a DC two-wire link between two boards.
CATEGORY
Connectivity & communications; Industrial
PARTS IN DESIGN / BOM BY STORE
Grayed out parts are unavailable for purchase on Avnet Abacus.
The displayed part lists is a small subset of the complete BOM.
| MFGR | PART# | BLK NM |
|---|---|---|
| Samtec | SSQ-106-03-L-S | Socket Connector |
| Samtec | SSQ-108-03-L-S | Socket Connector |
| TE Connectivity | 282837-2 | Header Connector |
| Samtec | SSQ-110-03-L-S | Socket Connector |
If you are not a customer of Avnet Abacus, please Register Here for Design Hub to interact with the AVAIL design tool and view BOM lists.
| MFGR | PART# | BLK NM |
|---|---|---|
| STMicroelectronics | ST7580TR | Line Driver |
| MFGR | PART# | BLK NM |
|---|---|---|
| STMicroelectronics | ST7580TR | Line Driver |
