i.MX RT1170 Evaluation Kit based on NXP Solution
The i.MX RT1170 EVK provides a high-performance solution in a highly integrated board. It consists of a 6-layer PCB with through hole design for better EMC performance at a low cost, and it includes key components and interfaces. Features NXP's i.MX RT1170, first GHz Crossover MCU with Arm Cortex-M7 and Cortex-M4 Cores.
CATEGORY
Analog; Embedded; Hardware
REFERENCE DESIGN
PARTS IN DESIGN / BOM BY STORE
Grayed out parts are unavailable for purchase on Avnet Silica.
The displayed part lists is a small subset of the complete BOM.
| MFGR | PART# | BLK NM |
|---|---|---|
| Semtech | RClamp0854P.TCT | TVS Diode |
| onsemi | FAN2558SX | LDO Regulator |
| NXP | MIMXRT1176CVM8A | Microcontroller |
| onsemi | NCP603SNADJT1G | Voltage Reference |
| Western Digital Corp | SDSDQAF3-008G-I | Flash Memory |
| Microchip | MIC2841AYMT-TR | LED Driver |
| onsemi | NCP164ASN180T1G | LDO Regulator |
| NXP | PCAL6416AEX1Z | Expander |
| Micron | MT48LC16M16A2P-6A IT:G TR | Voltage Reference |
| Nexperia | PRTR5V0U2X,215 | ESD Suppressor |
| Semtech | SRV05-4.TCT | ESD Suppressor |
| NXP | TJA1057GT/3J | CAN Transceiver |
| Micron | MT29F1G08ABAEAH4-AATX:E | Flash Memory |
| STMicroelectronics | TCPP01-M12 | ESD Suppressor |
| onsemi | NL17SZ126DFT2G | Buffer |
| Cirrus Logic | WM8962BECSN/R | Audio CODEC |
| Microchip | MIC2545A-2YTS | Current Limit Switch |
| MPS | MP2143DJ-LF-Z | Voltage Reference |
| Macronix | MX25U51245GXDI00 | Flash Memory |
| onsemi | FDMA530PZ | MOSFET |
| Microchip | KSZ8081RNBIA-TR | Voltage Reference |
| STMicroelectronics | EMIF06-HSD03F3 | EMI Filter |
| Microchip | MIC826LYMT-TR | Voltage Supervisor |
| Diodes Inc | 74LVC1G3157FZ4-7 | Voltage Reference |
If you are not a customer of Avnet Silica, please Register Here for Design Hub to interact with the AVAIL design tool and view BOM lists.
| MFGR | PART# | BLK NM |
|---|---|---|
| Amphenol | GTFP08431BEU | Voltage Reference |
| Amphenol | SLW24S-1C7LF | FFC/FPC Connector |
| TE Connectivity | 2134536-2 | USB Connector |
| CTS | 405C35B25M00000 | Crystal Oscillator |
| Amphenol | 68000-103HLF | Header Connector |
| ECS Inc. International | ECS-.327-7-34B-TR | Crystal Oscillator |
| CTS | 218-4LPSTR | Switch |
| PUI Audio | TOM-1545P-R | Microphone |
| Amphenol | 68000-102HLF | Header Connector |
| Abracon | ARJE-0034 | RJ45 Connector |
| Abracon | ASEDV-24.000MHZ-LR-T3 | Crystal Oscillator |
| CTS | LP120F33IDT | Crystal Oscillator |
| Molex | 1054500101 | USB Connector |
| CTS | 218-10LPST | Voltage Reference |
| LBEE5KL1YN | Wireless Module | |
| Samtec | TSW-105-05-G-D | Header Connector |
| Murata | XRCGB24M000F2P00R0 | Crystal Oscillator |
| Amphenol | 10038075-D1PLF | Jack Connector |
| Samtec | TSW-110-05-G-D | Header Connector |
| Pulse Electronics | W3008 | Antenna |
| SCHURTER | 1301.9315 | Tactile Switch |
