dh designs/silica/designs/3kw-power-supply-based-on-onsemi-solution 3kW Power Supply based on onsemi Solution

Script Application

3kW Power Supply based on onsemi Solution

3kW Power Supply based on onsemi's EliteSiC solutions. Features PFC, LLC, and SR topologies. Target applications include energy infrastructure and storage, robotics, industrial drives and pumps, power supplies, and Li-ion chargers.

MFGR	PART#	BLK NM
onsemi	NCP4390DR2G	DC to DC Controller
onsemi	FAN7191MX_F085	Gate Driver
onsemi	NTBLS1D1N08H	MOSFET
onsemi	NCP51560BBDWR2G	Gate Driver
onsemi	NTHL045N065SC1	SiC MOSFET
onsemi	NCP81075MNTXG	Gate Driver
onsemi	NCD57530DWKR2G	Gate Driver
onsemi	FCH023N65S3L4	MOSFET
onsemi	NCP1681ABD2R2G	PWM Controller

av-dh-disclaimer-silica

IMPORTANT NOTICE AND DISCLAIMER: AVNET PROVIDES THESE DESIGN FILES “AS IS” AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD PARTY. SEE LEGAL NOTICES | AVNET EMEA FOR ADDITIONAL INFORMATION.

silica content library/home/design/av-dh-disclaimer-silica av-dh-disclaimer-silica
