SiC MOSFETs raise the bar for safe, robust and reliable power switching. Excellent RDS(on) temperature stability, fast switching speed, and high short-circuit durability, making them ideal for high-power and high-voltage industrial applications. The devices offers superior gate charge characteristics and an optimized gate charge ratio, enabling low power consumption in gate drivers and high immunity to parasitic turn-on effects. With ultra-small threshold voltage tolerance, a robust body diode featuring very low forward voltage, and minimal leakage current up to 1200 V, it ensures reliable and efficient performance across demanding applications.
SiC Mosfets
| VDS (V) | RDSon (mΩ) @18V VGS |
RDSon (mΩ) @15V VGS |
TO-247-3 | TO-247-4 | TO-263-7 | X.PAK |
|---|---|---|---|---|---|---|
| 1200 | 17 | ✔ | ||||
| 30 | 40 | ✔ | ✔ | ✔ | ✔ | |
| 40 | ✔ | ✔ | ✔ | |||
| 60 | 80 | ✔ | ✔ | ✔ | ✔ |
X.PAK - Performance and ease-of-use for PV Inverter Rectification
1200 V SiC MOSFETs in X.PAK package deliver advanced thermal management and power density for high-power applications. The innovative surface-mount (SMD) top-side cooled package X.PAK combines the assembly simplicity of SMD with the cooling efficiency of through-hole technology.
- High Voltage Capability (1200 V) ideal for DC bus voltages in both residential and industrial PV systems
- Low RDS(on) minimizes conduction losses, improving overall system efficiency
- Industry-Leading Temperature Stability
RDS(on) increases by only 38% over a wide operating range from 25 °C to 175 °C, ensuring consistent performance under thermal stress - Top-Side Cooling (X.PAK Package) enables efficient heat dissipation in compact inverter designs, enabling higher power density and simplified heatsink integration
- Kelvin Source Pin enhances gate drive control and reduces switching noise - critical for high-frequency inverter operation
- Robust Body Diode supports fast reverse recovery and ruggedness, ideal for hard-switching environments in full-bridge inverter topologies.
