STMicroelectronics TSV771IY
TSV771IY - High bandwidth (20 MHz) low offset (200 µV) rail-to-rail 5V Op amp
The TSV771IY is a dual 20 MHz-bandwidth unity-gain-stable amplifier. The rail-to-rail input stage and the slew rate of 13 V/µs make the TSV771IY ideal for low-side current measurement. The excellent accuracy provided by maximum input voltage of 200 µV allows amplifying accurately small-amplitude input signal. The TSV771IY can operate from a 2.0 V to 5.5 V single supply and is fully characterized for an output capacitor of 47 pF, for easy usage as an A/D converter input buffer.
Features
- Gain bandwidth product 20 MHz, unity gain stable
- Low input offset voltage: 50 µV typ., 200 µV max.
- Low input bias current: 2 pA typ.
- Low noise: 7 nV/√Hz
- Slew rate: 13 V/µs
- Wide supply voltage range: 2.0 V to 5.5 V
- Rail-to-rail input and output
- 4 kV HBM ESD tolerance
- Input common-mode range includes low rail
- Extended temperature range: -40 °C to +125 °C
- Automotive grade versions available
- Benefits:
- Accuracy of measurement virtually unaffected by noise or input bias current
- Signal conditioning for high frequencies
KITOPAMP1120 - High-performance Op Amps Sample kit
The KITOPAMP1120 provides a selection of operational amplifiers and comparators useful for evaluation and to promote the product family.
Features
- Immediate evaluation of high-performance op amps with:
- samples of 18 operational amplifiers
- samples of 3 comparators
- The sample kit includes a printed card providing:
- Overview of product portfolio
- Recommended products
- Featured families
- ST op amps naming rules
- Resources: ST op amps mobile application, eDesignSuite
