Advantech AIMB-292

The Advantech AIMB-292 is an industrial-grade motherboard designed to meet the rigorous demands of AI and edge computing applications. Key features include:

• Processing Power: Supports 12th, 13th, and 14th Gen Intel^® Core™ Desktop Processors (up to 24 cores) paired with a Q670E chipset for high-performance computing.
• Advanced Graphics & Memory: Integrated NVIDIA MXM graphics and dual SO-DIMM slots enable support for up to 96GB DDR5 memory, delivering impressive AI computing power-up to 17.66 TFLOPS-for advanced visual processing and machine learning inference. PROXIS.UA
• Display & Connectivity: Offers quadruple display outputs (3 DisplayPort and 1 LVDS/eDP) capable of up to 4K resolution, along with extensive expansion options including one M.2 M-key, one M.2 E-key, 4 USB 3.2 Gen2 ports, 2 USB 2.0 ports, and a SATA III interface.
• Edge AI Ready: Certified for Edge AI SRP of WISE-DeviceOn and Embedded Software APIs, the AIMB-292 is optimized for rapid development and deployment of AI applications at the edge.
• Form Factor & Durability: With a compact Mini-ITX design and advanced thermal management (via the Advantech QFCS solution), this motherboard is ideal for space-constrained and rugged industrial environments.

Key features

• 12/13/14th Gen Intel^® Core™ desktop processors, max. 24 Core, support Q670E chipset
• Integrated NVIDIA MXM graphics
• Up to 96GB DDR5 5600 MT/s with two SO-DIMM
• Quadruple displays with 3 DP and 1 LVDS (or eDP), up to 4K
• Abundant expansion: 1 M.2 M-key & 1 M.2 E-key, 4 USB 3.2 Gen2x1, 2 USB 2.0, 1 SATA III
• Qualified for Edge AI SRP of WISE-DeviceOn and Embedded Software APIs

Applications

• AI Inference
• Visual processing
• Industrial IoT
• Edge computing
